RV921 Receiver Card

RV921 Features:

1. Support 12-bit HDMI the colors input (required nine generations, sent cards fit);

2. By 18 signal processors, maximum support of each RGB 18 (260,000) Gray 1024X256 pixels;

3. Single card maximum support 1024 single point chromaticity correction;

4. Supports single-card color space conversion;

5. Support configuration file readback;

6. Support program replication;

7. Supports dual hot backup receiver card for demanding performances screen;

8.Supports pixel fault detection (requires a dedicated chip support);

9. Support network cable BER test;

10. Support cable fault detection;

11. Support the cabinet door switch monitoring;

12. Two fan speed monitoring;

13. Voltage monitoring of the 13 three-way all the way for the system, two external box power;

14. Temperature monitoring;

15. Humidity monitor (need to buy humidity sensor separately);

16. Smoke monitor (need to buy smoke module separately);

17. With EU standards CE-EMC;

18. A single card can output 16 sets of RGBR’data;

19. A single card can output 20 sets of RGB data;

20. A single card can output 32 sets of serial data;

21. Single card supports 1024 x 256 pixels;

22. Support point-by-point brightness correction and single card chroma space conversion;

23. Supporting network line error testing;

24. Supporting the high brush and high ash of most chips.
